Key Features
- Ergonomically designed for hazard avoidance with OFF&rArrON&rArrOFF, 3-position operation.
- From position 1&rArr2, a snap-action switch is built-in for a crisp operation feel, making position 2 easy to identify.
- From position 2&rArr3, a heavy and reliable operation feel.
- Reduced holding force at position 2 to accommodate long-duration operation.
- Stable and reliable operation feel even when operating the edge of the button.
- The structure prevents the ON state between pressing OFF (position 3) and releasing OFF (position 1). (IEC60204-1 Clause 9.2.5.8, IEC60947-5-8 Clause 7.1.9)
- Built-in 2 contacts in the 3-position switch allow for redundancy for safety.
- Rubber cover version supports waterproof construction (IP65).
Specifications
Expand All
+Documents and Files
Enabling Switches Catalog
04/09/2025.PDF1.17MB
